CB500X

CB500X

Specifications & Price

Your bike in detail

Select a bike to display specification details.

CB500X 2021

Choose variant (3)

CB500X 2021



Grand Prix Red

Choose colour (3)

CB500X 2021

CB500X 2021 Specifications ▲

Show specifications

  • Engine
    Bore × Stroke (mm) 67mm x 66.8mm
    Carburation PGM-FI electronic fuel injection
    Compression Ratio 10.7:1
    Engine Displacement (cm3) 471cc
    Engine Type Liquid-cooled 4-stroke DOHC parallel twin
    Max. Power Output 35kw/8,600rpm
    Max. Torque 43Nm/6,500rpm
    Starter Electric
    Throttle Bore 34
    C02 Emissions (g/km) 82
  • Wheels
    Brakes Front 310 mm x 5 mm disc with two piston caliper
    Brakes Rear 240 mm x 5 mm disc with single piston caliper
    Suspension Front Conventional Telescopic, 41mm, pre-load adjustable
    Suspension Rear Prolink mono with 5 stage Pre-load adjuster, steel square pipe swingarm
    Tyre Size Front 110/80R19M/C
    Tyre Size Rear 160/60ZR-17M/C
    Wheels Front Multi-Spoke Cast Aluminium
    Wheels Rear Multi-Spoke Cast Aluminium
    ABS System 2 channel
  • Dimensions and Weights
    Battery Capacity (VAh) 12v 7.4Ah
    Caster Angle 27.5°
    Dimensions (L×W×H) (mm) 2,155mmX825mmX1,410mm
    Frame type Steel diamond
    Fuel Tank Capacity (Litres) 17.5L
    Fuel Consumption 27.8km/L / 3.5l/100km
    Ground Clearance (mm) 180mm
    Kerb Weight (kg) 197kg
    Seat Height (mm) 830mm
    Trail (mm) 108mm
    Wheelbase (mm) 1,445mm
  • Transmission
    Clutch Wet multiplate, A.S.clutch
    Final Drive Chain
    Gearbox 6-speed
  • Instruments and Electrics
    Headlights LED
    12v Socket Optional
    Instruments LCD Meter with Speedometer, Bar Graph Tachometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Water Temp, Gear position, Shift UP Indicator
    Security HISS
    Tail Light LED
  • Additional Features
    Additional Features HSTC

▲
