Specifications
CRF125F 2023
-
Bore × Stroke (mm)
52.4mm x 57.9mm
-
Carburation
Fuel-injection, 22mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cm3)
124.9cc
-
Engine Type
Air-cooled single-cylinder four-stroke
-
Brakes Front
220mm hydraulic disc
-
Brakes Rear
Drum
-
Suspension Front
31mm telescopic fork; 13cm of travel
-
Suspension Rear
Pro-Link® single-shock; 14cm of travel
-
Tyre Size Front
70/100-17
-
Tyre Size Rear
90/100-14
-
Caster Angle
27°30'
-
Fuel Tank Capacity (Litres)
4.54
-
Ground Clearance (mm)
21cm
-
Kerb Weight (kg)
88kg
-
Seat Height (mm)
738mm
-
Trail (mm)
81mm
-
Wheelbase (mm)
122cm
-
Final Drive
Chain
-
Gearbox
Four-speed
-
Ignition System
Full Transistorized
CRF125F Big Wheel 2023
-
Bore × Stroke (mm)
52.4mm x 57.9mm
-
Carburation
Fuel-injection, 22mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cm3)
124.9cc
-
Engine Type
Air-cooled single-cylinder four-stroke
-
Brakes Front
220mm hydraulic disc
-
Brakes Rear
Drum
-
Suspension Front
31mm telescopic fork; 13cm of travel
-
Suspension Rear
Pro-Link® single-shock; 14cm of travel
-
Tyre Size Front
70/100-17
-
Tyre Size Rear
90/100-14
-
Caster Angle
27°30'
-
Fuel Tank Capacity (Litres)
4.54
-
Ground Clearance (mm)
21cm
-
Kerb Weight (kg)
88kg
-
Seat Height (mm)
785mm
-
Trail (mm)
81mm
-
Wheelbase (mm)
122cm
-
Final Drive
Chain
-
Gearbox
Four-speed
-
Ignition System
Full Transistorized
CRF125F 2022
-
Bore × Stroke (mm)
52.4mm x 57.9mm
-
Carburation
Fuel-injection, 22mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cm3)
124.9cc
-
Engine Type
Air-cooled single-cylinder four-stroke
-
Brakes Front
220mm hydraulic disc
-
Brakes Rear
Drum
-
Suspension Front
31mm telescopic fork; 13cm of travel
-
Suspension Rear
Pro-Link® single-shock; 14cm of travel
-
Tyre Size Front
70/100-17
-
Tyre Size Rear
90/100-14
-
Caster Angle
27°30'
-
Fuel Tank Capacity (Litres)
4.54
-
Ground Clearance (mm)
21cm
-
Kerb Weight (kg)
88kg
-
Seat Height (mm)
74cm
-
Trail (mm)
81mm
-
Wheelbase (mm)
122cm
-
Final Drive
Chain
-
Gearbox
Four-speed
-
Ignition System
Full Transistorized
CRF125F Big Wheel 2022
-
Bore × Stroke (mm)
52.4mm x 57.9mm
-
Carburation
Fuel-injection, 22mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cm3)
124.9cc
-
Engine Type
Air-cooled single-cylinder four-stroke
-
Brakes Front
220mm hydraulic disc
-
Brakes Rear
Drum
-
Suspension Front
31mm telescopic fork; 13cm of travel
-
Suspension Rear
Pro-Link® single-shock; 14cm of travel
-
Tyre Size Front
70/100-17
-
Tyre Size Rear
90/100-14
-
Caster Angle
27°30'
-
Fuel Tank Capacity (Litres)
4.54
-
Ground Clearance (mm)
21cm
-
Kerb Weight (kg)
88kg
-
Seat Height (mm)
74cm
-
Trail (mm)
81mm
-
Wheelbase (mm)
122cm
-
Final Drive
Chain
-
Gearbox
Four-speed
-
Ignition System
Full Transistorized
CRF125F 2020
-
Bore × Stroke (mm)
52.4mm x 57.9mm
-
Carburation
Fuel-injection, 22mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cm3)
124.9cc
-
Engine Type
Air-cooled single-cylinder four-stroke
-
Brakes Front
220mm hydraulic disc
-
Brakes Rear
Drum
-
Suspension Front
31mm telescopic fork; 13cm of travel
-
Suspension Rear
Pro-Link® single-shock; 14cm of travel
-
Tyre Size Front
70/100-17
-
Tyre Size Rear
90/100-14
-
Caster Angle
27°30'
-
Fuel Tank Capacity (Litres)
4.54
-
Ground Clearance (mm)
21cm
-
Kerb Weight (kg)
88kg
-
Seat Height (mm)
74cm
-
Trail (mm)
81mm
-
Wheelbase (mm)
122cm
-
Final Drive
Chain
-
Gearbox
Four-speed
-
Ignition System
Full Transistorized
